Hydraulic Fluid in a Flexible Diaphragm Hydroforming Presses
Hydroforming presses of Hephaestus-N.06 series with CNC are designed for hydraulic forming of parts of complex spatial shape made of steel, non-ferrous alloys and titanium by pressing with hydroelastic medium.
The sheet metal takes the form of a solid one-sided matrix under the action of an elastic rubber membrane, the surface of which is pressurized by a working fluid (costor oil). High accuracy of the shape of the matrix is achieved by hydrostatic compression of the sheet, where the pressure exerted on the surface is the same at all points of the surface and does not depend on the shape of the surface.
The sheet metal takes the form of a solid one-sided matrix under the action of an elastic rubber membrane, the surface of which is pressurized by a working fluid (costor oil). High accuracy of the shape of the matrix is achieved by hydrostatic compression of the sheet, where the pressure exerted on the surface is the same at all points of the surface and does not depend on the shape of the surface.
- Progressive engineering
- Aircraft manufacturing
- Spacecraft manufacturing
- Production of prototypes
- Production of complex parts in small batch production
- Columnar prefabricated bed
- Hydraulic components Hawe, Bosch-Rexroth
- Electrical components Siemens, Schneider Electric, Omron
- Diaphragm made in Germany or USA
- Open Software - Hydropress™
- No scratches on the surface of the part. No need for finishing machining.
- Small tolerances on the part relative to the die due to high hydrostatic pressure.
- Possibility to trim the part directly in the pressing process.
- Low cost of the die, short lead times.
- Production of complex shaped parts, including cutouts and bending edges.
- Reduction of the time of preparation for production and easy finalization of the die when making changes in the design of the product.
#rec943579281
- Two loading tables
- Pump for pumping oil into the hydraulic system
- Water oil cooler
- OMRON controller with LCD display
- Remote control panel
- Laser system to protect the working area
- Manual and automatic operation modes
- Extraction into polyurethane matrix
- Increased capacity hydraulic system
- Water recycling systems with water softening
