Automatic Double Cylinders Presses
The MUSKUL DUO and Muskul KPRZ-400M.04 series automatic presses are a unique development of Gidropress, designed especially for the railway enterprises of Russia, Belarus and Kazakhstan.
This type of presses is designed mainly for enterprises working with a wide range of wheelsets. These are wheelsets of trams, locomotives, freight cars, subway cars. It is suitable both for new wheelsets and for repair shops.
The presses are recognized in developing countries in Africa, Asia, South America. Why? Wide functionality of settings, reduced requirements to the qualification of the operator, possibility to press almost any wheelset - this is not a complete list of advantages of the Muskul KPRZ-M.04 DUO double-sided press.
This type of presses is designed mainly for enterprises working with a wide range of wheelsets. These are wheelsets of trams, locomotives, freight cars, subway cars. It is suitable both for new wheelsets and for repair shops.
The presses are recognized in developing countries in Africa, Asia, South America. Why? Wide functionality of settings, reduced requirements to the qualification of the operator, possibility to press almost any wheelset - this is not a complete list of advantages of the Muskul KPRZ-M.04 DUO double-sided press.
A special feature of the press is the movable center beam. It not only moves horizontally, but also has the ability to move out of the press area and to move to the side to make room. The crosshead itself has two pressure brackets. One can be used for pressing and the other for unpressing. Or for pressing different elements.
This solution makes it possible to work on the same type of wheel set without having to readjust the tool and spend time adjusting it to a new task.
To improve the quality of the press and the repeatability of the cycle, the most advanced solutions have been applied in the press. These include axle centering. Separate hydraulic system for each power cylinder. A non-contact laser system to measure the linear accuracy of the press. And wheel runout monitoring directly in the press.
After the carriage loads the wheel axle into the press, the hydraulic cylinders' extension centers lock the axle to the press centerline. The spring-loaded centers fold inward as the press begins to press the wheel. In this way, the auxiliary force does not interfere with the force-path diagram. The centers have interchangeable 90- and 60-degree cones for different axle types.
Measurement - This is the part where we use the world's best practices. Bosch and Hiwin equipment is interchangeable, has high wear resistance of linear systems, holds declared loads and copes well with the harsh conditions of railroad depots.
Press controls. We most often choose the Japanese Omron. For the best price/performance ratio. It is well supported worldwide. If a customer asks for Siemens, we work with Siemens. It is probably the most developed system in the world at the moment. But! The support of the license software, the long delivery times of the components and the possibility of technical support in a number of countries leaves much to be desired.
This solution makes it possible to work on the same type of wheel set without having to readjust the tool and spend time adjusting it to a new task.
To improve the quality of the press and the repeatability of the cycle, the most advanced solutions have been applied in the press. These include axle centering. Separate hydraulic system for each power cylinder. A non-contact laser system to measure the linear accuracy of the press. And wheel runout monitoring directly in the press.
After the carriage loads the wheel axle into the press, the hydraulic cylinders' extension centers lock the axle to the press centerline. The spring-loaded centers fold inward as the press begins to press the wheel. In this way, the auxiliary force does not interfere with the force-path diagram. The centers have interchangeable 90- and 60-degree cones for different axle types.
Measurement - This is the part where we use the world's best practices. Bosch and Hiwin equipment is interchangeable, has high wear resistance of linear systems, holds declared loads and copes well with the harsh conditions of railroad depots.
Press controls. We most often choose the Japanese Omron. For the best price/performance ratio. It is well supported worldwide. If a customer asks for Siemens, we work with Siemens. It is probably the most developed system in the world at the moment. But! The support of the license software, the long delivery times of the components and the possibility of technical support in a number of countries leaves much to be desired.
- Fully automated wheel set pressing/unpressing process
- Highest measuring accuracy and process repeatability
- Highest productivity required for series production
- No human factor influence
- Working with ANY type of wheelsets
- Process control during execution
- Low energy consumption
- Possibility of integration into an automatic wheel set forming line
- Fast and accurate movements due to modern proportional control system, heat-treated and ground guides and high quality of press assembly
- Guarantee of reliability and durability thanks to components of world-famous European brands
#rec940461606
- Press complete with hydraulic unit
- Automatic loading arm
- Remote control panel
- Electronic recorder “Effort-Path”
- Automatic CNC complex “Press-Vagon-E”
- Automatic control system
- Tooling set for pressing and unpressing of control gearboxes
- KP preassembly bench
- Printing of the pressing protocol on the printer
Microprocessor control system ensures the complex operation in fully automatic mode.
The control system registers:
Omron controller and software in Russian language allow to control and document a lot of technological data in the process. The complex has an electronic recorder “Force-Put”, entered in the register of measuring instruments.
The control system registers:
- Force and displacement at each end of the axis
- Control parameters of end runout and radial runout (optional)
Omron controller and software in Russian language allow to control and document a lot of technological data in the process. The complex has an electronic recorder “Force-Put”, entered in the register of measuring instruments.
